Crompton Instruments - Digital Metering

Our versatile range INTEGRA digital metering systems and power quality systems (dms) enables cost effective solution for the measurement and display of all electrical parameters including total harmonic distortion (THD) and individual, up to the 63rd harmonics. Meters are available in DIN96 panel mounted or DIN-rail enclosures.

Models

Integra 1222 Digital Metering

DIN 96 enclosure
Backlit LCD screen
Voltage IN-OUT connections
CT current measurement 5A/1A
Plug and socket connections
Programmable VT, CT ratios
Modbus™ RTU
Individual harmonics to 63rd
Non-volatile memory 1MB

Integra 2270 Power Quality Meter

Waveform capture 8 cycles per phase
Sags/swells monitoring to BS EN 50160
Accuracy to 0.2S% (reading)
User programmable configuration
Min/Max value stored in non-volatile memory
Hours run
Supported real time clock
Soft alarms

Integra INT1022 Multifunction Meter

Accuracy Class 1
Independent Import & Export Energy counter
True RMS measurements up to 31st Harmonic
Programmable PT/CT ratios
3 Line, 4 Digit bright Red LED display and indication LEDs
• 96x96mm DIN

Integra 1222 Digital Metering

INT1222

The Crompton Instruments Integra 1222 digital metering system (dms) from TE Connectivity enables cost effective solution for the measurement and display of all electrical parameters including total harmonic distortion (THD) and individual, up to the 63rd harmonic.

Integra 2270 Power Quality Meter

INT2270

The Integra 2270 digital meter provides measurement, isolation and conversion of all main electrical parameters and can be used in single-phase and three-phase three-wire unbalanced, four-wire balanced and unbalanced systems. RS485 Modbus RTU communications protocol, pulse/alarm outputs and inputs are fitted as standard.

Integra INT1022 Multifunction Meter

INT1022

TE Connectivity’s (TE) Crompton Instruments Integra 1022 Multifunction Meter
measures important electrical parameters in 3phase 4wire, 3phase 3wire, 1phase
2wire and 1phase 3wire network.
It displays many parameters at a glance. It measures electrical parameters like
Active/Reactive/Apparent energy, power and all basic parameters. The instrument
has one optional built in Relay output which can be configured as pulse output for
energy measurement, as well as limit output. Optional MODBUS RTU over RS-485 is
built in for remote monitoring and configuration.
The Integra 1022 multifunction instrument is a panel mounted 96 x 96mm DIN.
